1） Parameters

2) Application

- Zone 1 and Zone 2 explosive gas environment; Zone 21 and Zone 22 flammable dust environment;

’Bi-environment’ with both explosive gas and flammable dust.

- Hazardous circumstances with T1-T4 temperature grouping and IIA, IIB & IIC explosive gas grouping.

- Application industries, including petrochemical, petroleum, chemical, metallurgy, logistics, aerospace, painting, coating, war industry, etc.

- Loading, unloading, stacking and transporting area for hazardous material production and storage.

3) Features

Reliability

The robustness of the steering control, the strong towing mouting and the high quality steel chassis ensure reliable operation over long periods of time. Extensive testing in the heaviest applications confirm the tractors' reliability.

Comfort

In addition to an adjustable backrest abd console/steering control, these tow tractor provides a unique suspened and damped "U"shape platform. This links the 3 main point of contact between operator and machine:scoop seat, platform and console and provides a suprior driving experience over long travel distance or uneven floors.

Console and twin grip steering control

- Ergonomically designed console incorporates steering control, clipboard, emergenc isolator CAN-bus plug and Linde Digital Information Dispaly(hourmeter, battery Discharge Indicatorm, warning and information dispaly)

- Adjustable in heigt, the console provide controls and instrumentation all within easy reach.

- All main control functions integrated into one handle for operation by both or either hand.

1）XP-Supe explosion-proof system: effectively control various ignition sources of vehicle

- Electric circuit and element protection: housing treatment and surface temperature limitation to meet safety requirements in dangerous environment.

- Power supply: International-brand explosion-proof battery, high-quality  housing and explosion-proof connectors realize high performance, safety and long life-time.

- Advanced overload sensing device: all-time monitor surface temperature of high-heat parts and automatically react once achieve threshold.

- Vehicle electricity isolation protection: monitoring isolation between  electrical elements and the vehicle frame continuously, and automatic alarm in abnormal situation.

- Equip with explosion-proof instruments, switches, horns, lamps and lanterns.

2）XP-Air(E) explosion-proof system: prviode Zone 2 active protection for electric vehicle

- Detection and control: continuous monitor explosive gas density, and automatic alarm or shutdown once density reaches setting level. Emergency stop for manual operation.

- Compulsory self-check procedure: check electric components working condition and flammable gas density for safety start and operation.

- Temperature controlling device: continuously detect and control surface temperature of the high-heat parts for temperature limitation.

- Protect vehicle components from possible arc, spark and static.
